CAP./SIZE

1t

2.2t

4.7t

10t

15t

22t

33t

47t

68t

100t

150t

220t

330t

470t

ΦA

49

49

49

74

75

75

95

130

130

150

150

225

225

270

ΦB

20

20

20

30

30

30

40

60

60

70

70

100

100

120

ΦC

60

60

60

75

75

75

95

130

130

150

150

225

225

270

H

43

43

43

50

50

50

65

75

85

90

100

130

145

170

J

-

-

-

7

7

7

7

7

7

7

7

10

10

10

K

7.5

7.5

7.5

6.5

6.5

6.5

10

14

14

16

16

24

24

28

R

15

15

15

25.4

25.4

25.4

50

60

-

-

-

-

-

-

Deep

2.2

2.2

2.2

3.3

3.3

3.3

3.3

5.1

-

-

-

-

-

-

Item Parameter

C3

Unit

Rated load (Emax):

1~470

t

Maximal numbers of load cell verification Intervals (Nlc):

3000

d

Minimum load cell verification intervals Intervals

( Vmin):

0.01

% of rated load

Rated output (Cn):

2.0±0.1%

mV/V

Combined error:

0.015

-% of rated output

Temperature effect on sensitivity(Tkc):

0.0012

=% of rated output/

Temperature effect on zero balance(Tk0):

0.0008

-% of rated output

Zero balance:

1.0

-% of rated output

Input resistance(Rlc):

775±5/＞=33t：1550± 10

Ω(Ohms)

Output resistance(Ro):

702±2/＞=33t：1402± 2

Ω(Ohms)

Insulation resistance:

≥5000

MΩ (Mega-Ohms)

Safe overload:

150

% of rated capability

Ultimate overload:

300

% of rated capability

Operating temperature range:

-20~+70/-20~+160

℃/ °F

Recommend excitation:

8~24

V( DC or AC)

Maximum excitation:

48

V( DC or AC)

Material of elastomer:

Alloy steel / Stainless steel

Protection class:

IP67/IP68
