Application
● No leakage of the pump body, wide application to industries such as treatment of drinking water and waste water;
● An economical option for meeting the requirements of high operational safety and reliability.
Advantage
Extremely High Operational Safety
● Excellent double-membrane design, pressed multi-layer membrane structure for even and durable stress-loading of the membrane;
● Good-quality materials and specially treated membrane for high pressure bearing of the membrane sealing area and avoiding leakage;
● A membrane state monitoring system can send a signal when the membrane is damaged and continuously work until the damaged membrane is changed, and doesn’t cause pollution to the metering medium.
An Economical Method for the Dangerous Medium
● The high-grade PTFE double-membrane having excellent chemical corrosion resistance can guarantee the output of various chemicals at the low pressure;
● Surface maintenance of the pump head;
● The pump head may be made of 304, 316, 316L stainless steel, PVC, UPVC, PVDF, F4, hastelloy C, etc.
Accurate Eccentric Structure Design
● The high repeatability precision is guaranteed by the linear stroke length and the very accurate length adjustment.
Type |
Flow Rate L/H |
Motor Power |
Travelmm |
Stroke |
0.18KW~0.37KW |
||||
Discharge Pressure |
||||
DPMXW90/0.8 |
90 |
0.8 |
6 |
120 |
DPMXW120/0.8 |
120 |
0.8 |
6 |
160 |
DPMXW140/0.6 |
140 |
0.8 |
6 |
120 |
DPMXW180/0.6 |
180 |
0.8 |
6 |
160 |
DPMXW260/0.4 |
260 |
0.8 |
6 |
120 |
DPMXW350/0.3 |
350 |
0.8 |
6 |
160 |
