Application
● No leakage of the pump body, wide application to industries such as treatment of drinking water and waste water;
● An economical option for meeting the requirements of high operational safety and reliability.
Advantage
Extremely High Operational Safety
● Excellent double-membrane design, pressed multi-layer membrane structure for even and durable stress-loading of the membrane;
● Good-quality materials and specially treated membrane for high pressure bearing of the membrane sealing area and avoiding leakage;
● A membrane state monitoring system can send a signal when the membrane is damaged and continuously work until the damaged membrane is changed, and doesn’t cause pollution to the metering medium.
An Economical Method for the Dangerous Medium
● The high-grade PTFE double-membrane having excellent chemical corrosion resistance can guarantee the output of various chemicals at the low pressure;
● Surface maintenance of the pump head;
● The pump head may be made of 304, 316, 316L stainless steel, PVC, UPVC, PVDF, F4, hastelloy C, etc.
Accurate Eccentric Structure Design
● The high repeatability precision is guaranteed by the linear stroke length and the very accurate length adjustment.
Type |
Flow Rate L/H |
Motor Power |
Travel |
Stroke |
|
0.37KW |
0.55KW |
||||
Discharge Pressure |
|||||
DPMWAF360/0.7/0.8 |
360 |
0.7 |
0.8 |
6 |
120 |
DPMWAF450/0.6/0.8 |
450 |
0.6 |
0.8 |
8 |
120 |
DPMWAF600/0.5/0.8 |
600 |
0.5 |
0.8 |
8 |
160 |
DPMWAF750/0.4/0.5 |
750 |
0.4 |
0.5 |
10 |
120 |
