Option
● The pump head with a hydraulic membrane type, a plunger type and a piston type;
● Automatic emptying, pressure release and oil supply valves in the hydraulic membrane pump, with excellent performance, safety and no leakage;
● One-piece “Oude” worm gear variable transmission mechanism, with low noise and high efficiency;
● Simple, reliable and high-performance sleeve-adjustable eccentric transmission mechanism, with stepless stroke control between 0 and 100%;
● One-way valves on the inlet and the outlet adopt high-grade and anti-corrosive ball valves and linear tightness to effectively guarantee metering precision and fluidit;
● High-performance plungers and fillers and sealing components from Germany, long service life and excellent sealing performance;
● Oil immersion type lubrication, ensuring the long-time and reliable use of variable speed transmission parts;
● Adjusting range: 0*100% and metering precision: ±1%(adjusting range: 10-100%);
● The double-head pump and the flow rate adjusting mechanism are mutually independent, a proportioning addition pump can be made, and multiple heads are connected in parallel to 12 heads; and the pulse can be smoothened;
● The flow rate can be adjusted in various modes of artificial mode, electric mode, frequency conversion mode and pneumatic mode.
Type |
Flow Rate L/H |
Motor Power |
Plunger Diameter |
|
1.5KW |
2.2KW |
|||
Discharge Pressure Mpa |
||||
2DP(M)ZA20/50/60 |
20 |
50 |
60 |
10 |
2DP(M)ZA34/35/50 |
34 |
35 |
50 |
12 |
2DP(M)ZA56/21/31 |
56 |
21 |
31 |
15 |
2DP(M)ZA96/12.5/18 |
96 |
12.5 |
18 |
20 |
2DP(M)ZA160/7.5/11 |
160 |
7.5 |
11 |
25 |
2DP(M)ZA230/5/7.5 |
230 |
5 |
7.5 |
30 |
2DP(M)ZA310/3.9/5.5 |
310 |
3.9 |
5.5 |
35 |
2DP(M)ZA400/3/4.4 |
400 |
3 |
4.4 |
40 |
2DP(M)ZA520/2.3/3.4 |
520 |
2.3 |
3.4 |
45 |
2DP(M)ZA640/1.9/2.7 |
640 |
1.9 |
2.7 |
50 |
2DP(M)ZA780/1.5/2.2 |
780 |
1.5 |
2.2 |
55 |
2DP(M)ZA920/1.3/1.9 |
920 |
1.3 |
1.9 |
60 |
2DP(M)ZA1090/1.1/1.6 |
1090 |
1.1 |
1.6 |
65 |
2DP(M)ZA1260/0.95/1.4 |
1260 |
0.95 |
1.4 |
70 |
2DP(M)ZA1450/0.8/1.2 |
1450 |
0.8 |
1.2 |
75 |
2DP(M)ZA1650/0.7/1 |
1650 |
0.7 |
1 |
80 |
2DP(M)ZA1860/0.6/0.95 |
1860 |
0.6 |
0.95 |
85 |
2DP(M)ZA2090/0.55/0.8 |
2090 |
0.55 |
0.8 |
90 |
2DP(M)ZA2350/0.5/0.75 |
2320 |
0.5 |
0.75 |
95 |
2DP(M)ZA2580/0.45/0.65 |
2580 |
0.45 |
0.65 |
100 |
2DP(M)ZA2790/0.43/0.6 |
2790 |
0.43 |
0.6 |
85(3) |
2DP(M)ZA3130/0.38/0.55 |
3130 |
0.38 |
0.55 |
90(3) |
2DP(M)ZA3490/0.34/0.5 |
3490 |
0.34 |
0.5 |
95(3) |
2DP(M)ZA3860/0.3/0.45 |
3860 |
0.3 |
0.45 |
100(3) |
