Option
● The pump head with a hydraulic membrane type, a plunger type and a piston type;
● Automatic emptying, pressure release and oil supply valves in the hydraulic membrane pump, with excellent performance, safety and no leakage;
● One-piece “Oude” worm gear variable transmission mechanism, with low noise and high efficiency;
● Simple, reliable and high-performance sleeve-adjustable eccentric transmission mechanism, with stepless stroke control between 0 and 100%;
● One-way valves on the inlet and the outlet adopt high-grade and anti-corrosive ball valves and linear tightness to effectively guarantee metering precision and fluidit;
● High-performance plungers and fillers and sealing components from Germany, long service life and excellent sealing performance;
● Oil immersion type lubrication, ensuring the long-time and reliable use of variable speed transmission parts;
● Adjusting range: 0*100% and metering precision: ±1%(adjusting range: 10-100%);
● The flow rate can be adjusted in various modes of artificial mode, electric mode, frequency conversion mode and pneumatic mode.
Type |
Flow Rate L/H |
Motor Power |
Plunger Diameter |
||
4KW |
5.5KW |
7.5KW |
|||
Discharge Pressur Mpa |
|||||
DP(M)DA42/80/90/95 |
42 |
80 |
90 |
95 |
15 |
DP(M)DA75/50/65/85 |
75 |
50 |
65 |
85 |
20 |
DP(M)DA125/30/40/55 |
125 |
30 |
40 |
55 |
25 |
DP(M)DA182/20/29/40 |
182 |
20 |
29 |
40 |
30 |
DP(M)DA247/15/20/29 |
247 |
15 |
20 |
29 |
35 |
DP(M)DA320/12/16/22 |
320 |
12 |
16 |
22 |
40 |
DP(M)DA405/9.5/13/18 |
405 |
9.5 |
13 |
18 |
45 |
DP(M)DA505/7.5/10/14.5 |
505 |
7.5 |
10 |
14.5 |
50 |
DP(M)DA612/6/8.5/12 |
612 |
6 |
8.5 |
12 |
55 |
DP(M)DA725/5.4/7.4/10 |
725 |
5.4 |
7.4 |
10 |
60 |
DP(M)DA855/4.5/6.3/8.5 |
855 |
4.5 |
6.3 |
8.5 |
65 |
DP(M)DA990/4/5.4/7.4 |
990 |
4 |
5.4 |
7.4 |
70 |
DP(M)DA1135/3.4/4.5/6.5 |
1135 |
3.4 |
4.5 |
6.5 |
75 |
DP(M)DA1295/3/4/5.5 |
1295 |
3 |
4 |
5.5 |
80 |
DP(M)DA1480/2.5/3.6/5 |
1480 |
2.5 |
3.6 |
5 |
85 |
DP(M)DA1660/2.3/3.2/4.4 |
1660 |
2.3 |
3.2 |
4.4 |
90 |
DP(M)DA1850/2.1/2.9/4 |
1850 |
2.1 |
2.9 |
4 |
95 |
DP(M)DA2050/1.9/2.6/3.5 |
2050 |
1.9 |
2.6 |
3.5 |
100 |
DP(M)DA2500/1.5/2.1/2.9 |
2500 |
1.5 |
2.1 |
2.9 |
110 |
DP(M)DA2960/1.3/1.8/2.4 |
2960 |
1.3 |
1.8 |
2.4 |
120 |
DP(M)DA3500/1.1/1.5/2 |
3500 |
1.1 |
1.5 |
2 |
130 |
